INTERNET-OF-TOILET (IoT) FEATURES
• Fault detection with automated alert
• Self-diagnosis with recommended solutions
• Water consumption tracking
• Product activity monitoring to facilitate preventive maintenance services
• Monthly to yearly graphs and reports accessible via Rigel IoT dashboard

PRODUCT FEATURES
• Accurate Sense+ 3.0 sensor technology
• Anti-corrosion & rust resistant S/S grade 304 sensor cover panel
• Colour LED indication on sensor cover panel for different flushing stages
• Low lip design suitable for children
• Mechanical override button
• Excellent water efficiency
• Compact design with removable internal trap for easy cleaning
• PuraGlaze–Anti-Stain glaze
• Urinal with nozzle spray

PRODUCT SPECIFICATION
• Installation type: Wall-hung
• Dimension (ware): 390(L) x 390(W) x 890(H)mm
• Material (ware): Vitreous China
• Material (front panel): Stainless steel
• Material (button): Stainless steel, Mirror polished finish
• Inlet: Concealed back inlet, G1/2”
• Power input: 220 –240V AC 50/60Hz
• Typical sensing distance: 50 – 600mm
• Detection time: 6 seconds
• Operating water pressure: 100kPa -800kPa
• Discharge volume: Nominal 0.5 Litres/ flush
