Product Features

• Low-capacity pedestal water closet
• Pedestal toilet can be paired with Rigel concealed cistern or concealed box flush valve system

Product Specification

• Dimension: 675 (L) x 370 (W) x 410 (H) mm
• Material: Vitreous china
• Rough-in: P-trap 190mm | S-Trap 65mm
• Flushing type: Washdown
• Inlet: Top Inlet
• Inlet rubber bush: ø55mm
• Trap seal: 50mm minimum
• Minimum water pressure: 135 kPa

Discharge Volume

• Full flush: 4.5-6.0 litres per flush
• Reduced flush: 3.0 litres per flush

Standard Accessories

• FT-SC1028PS – Polypropylene soft-closing seat and cover
• FT-BSHWC5530 – WC inlet rubber bush, ID32mm
• FT-PCPS-VT103 – Flexible trap connector

Downloads

Cutsheet
