Product Features

• Touch-free flushing activation for optimum personal hygiene
• Water-saving dual flush operation
• Manual overriding button in case of power outage
• Anti-corrosion & anti-rust S/S grade 304 cover panel

Product Specification

• • Dimension (front panel): 180 (L) x 180 (H) mm
  • Panel wall opening: 169 (L) x 169 (H) mm
  • Material (front panel & frame): Stainless steel 304
  • Material (button): Stainless steel 304
  • Material (flush valve): Brass casting
  • Power input: 220-240 Vac 50/60Hz
  • Sensing distance: 900mm (default)
  • Detection time: 6 seconds
  • Manual override: Push button
  • Operating water pressure: Nominal 4.5 litres/flush (full), nominal 3.0 litres/flush (reduced)
  • Discharge volume: 4.0-5.0 litres/flush (full), ≤3.0 litres/flush (reduced)

Product Specification

• FT-LP7X3 – L-Pipe for WC – 700 (H) x 300 (L) x ø32 (Dia) mm, SUS304 OR
• FT-LP8X4 – L-Pipe for Squat Pan – 800 (H) x 400 (L) x ø32 (Dia) mm, SUS304

Downloads

Cutsheet Instruction Manual
